Reliable performance
● Both the battery side and the load side have super strong load capacity, smooth voltage and current waveforms, and can drive inductive loads such as air conditioning, supporting unlimited load.
● Independent intelligent load/generator interface, compatible with existing PV system access, can operate without batteries (PV+grid combined power supply).
● Even without a battery, it can be bypassed for output, important loads will not be powered off; The grid connected electricity sales function significantly improves energy utilization efficiency.
Economic benefits
● 2 MPPT channel, PV input can exceed 1.7-2 times the rated power, supporting simultaneous full power charging and load, maximizing economic benefits.
● Supports grid connected, off grid, and grid connected switching modes, with adaptive frequency and the ability to set charging and discharging strategies based on time of use electricity prices to achieve economical energy use.
Super Protection
● AICOT island protection, anti backflow (internal/external), PV reverse connection alarm, External CT reverse connection alarm and open circuit detection functions.
Friendly Design
● High definition touch screen and LED screen are optional, supporting multiple languages; Removable dust cover suitable for harsh environments; Support battery activation function.
| MODEL | HS1150EH48L |
| Battery Voltage | 48Vdc |
| Battery Type | Lead-acid, lithium batteries, gel batteries, etc |
| Output | |
| Rated Output Power | 15000VA/15000W |
| Parallel Function | N/A |
| Rated Output Voltage | 220/230Vac |
| Rated Output Frequency | 50/60Hz (± 5), intelligent adaptive / setting |
| Output Waveform | Pure sine wave |
| Max Efficiency(Peak) | 92% |
| Rated Current | 65.2A |
| Transfer Time | 10ms(Typical value) |
| PV Input | |
| Max PV Power | 20000W |
| MPPT Voltage Range | 370Vdc(90~500V) |
| Max Input Voltage | 500Vdc |
| Max Charging Current | 260A |
| Number of MPPT / Strings per MPPT | 2/1+1 |
| Mains/ Generator Input | |
| Max Charging Current | 120A |
| AC Input Voltage Range (UPS mode) | 170~280Vac,±2% |
| Rated Frequency | 50 / 60Hz |
| Battery Input | |
| Voltage Range | 40~60V |
| Max Charging Current | 260A |
| General Parameters | |
| Dimension. W*D*H(mm) | 425*140*605 |
| Installation Method | Wall-mounted |
| Weight (kg) | 21.5 |
| Communication Mode | Standard: RS485 / CAN, Optional 4G / WIFI |
| Protection function | Over/Under Voltage Protection、Over/Under Frequency Protection、AC Output Short Circuit Protection、AC Output Overload Protection、High/Low Temp Protection、PV Reverse Connection Alarm |
| Operating Environment | |
| Operating Ambient Temperature | -25℃~60℃(＞45℃ Derating ) |
| Storage Ambient Temperature | -20°C~60°C |
| Humidity | 0%~95% |
| Altitude | ＜2000m |
| Installation Environment | For indoor use only |
| Certifications | |
| Certification | CE 、RoHS |
| Certifications standard | IEC/EN 61000-6-1/3 、IEC/EN 61000-3-11/12、EN 62920 、IEC 62109-1、IEC 62109-2、IEC 62321 |
