It has the function of connecting to the power grid, which effectively improves the energy utilization efficiency.
It is equipped with a dimensional upgrade driving function, enabling a larger load power capacity and support for a wider variety of loads.
It adopts an advanced inverter architecture, which can reliably suppress leakage current and ensure electrical safety.
It can provide bypass output even without a battery, ensuring continuous power supply to critical loads.
The Max Supports up to 10 parallel machines, and three-phase group grid.
It is compatible with lead-acid batteries, lithium batteries, gel batteries, etc.
It has a battery activation function.
| MODEL | HS030ELS | HS040ELS | HS050ELS | HS050ELSP |
|---|---|---|---|---|
| Battery Voltage | 48Vdc | |||
| Battery Type | Lead-acid, lithium batteries, gel batteries, etc | |||
| Output | ||||
| Rated Output Power | 3000VA/3000W | 4000VA/4000W | 5000VA/5000W | 5000VA/5000W |
| Parallel Function | N/A | N/A | N/A | Yes, up to 10 units |
| Rated Output Voltage | 230Vac±4% | |||
| Rated Output Frequency | 50/60Hz±0.3(Adaptive) | |||
| Output Waveform | Pure sine wave | |||
| Max Efficiency(Peak) | 93.8% | |||
| Rated Current | 13A | 18A | 22A | 22A |
| Transfer Time | 10ms(Typical value) | |||
| PV Input | ||||
| Max Input Power | 3200W | 4500W | 4500W | 4500W |
| MPPT Voltage Range | 60~115Vdc | |||
| Max Input Voltage | 145Vdc | |||
| Max Charging Current | 60A | 80A | 80A | 80A |
| Mains/ Generator Input | ||||
| Max Charging Current | 30A | 60A | 60A | 60A |
| AC Input Voltage Range (UPS mode) | 170~280Vac,±2% | |||
| Frequency Range | (47-55Hz) ±0.3 / (57-65Hz) ±0.3 | |||
| Battery Input | ||||
| Voltage Range | 40~60Vdc | |||
| Max Charging Current | 90A | 140A | 140A | 140A |
| Default Charging Current | 30A | 30A | 30A | 30A |
| General Parameters | ||||
| Dimension. W*D*H(mm) | 470*330*125 | |||
| Installation Method | Wall-mounted | |||
| Weight (kg) | 12 | |||
| Communication Mode | RS485/Dry contact control, Optional WIFI/4G | |||
| Protection function | Over/Under Voltage Protection、Over/Under Frequency Protection、AC Output Short Circuit Protection、AC Output Overload Protection、High/Low Temp Protection | |||
| Operating Environment | ||||
| Operating Ambient Temperature | -25℃~60℃(>45℃ Derating ) | |||
| Storage Ambient Temperature | -20℃~60℃ | |||
| Humidity | 5%~95% Non-condensation | |||
| Altitude | 4000m(> 2000m Derating) | |||
| Protection Degree | IP20 (For indoor use only) | |||
| Certifications | ||||
| Certification | CE 、RoHS | |||
| Certifications standard | IEC/EN 61000-6-1/3 、IEC 62109-1、IEC 62109-2、IEC 62321 | |||
Specifications are subject to change without advance notice.
