The PV power can reach up to twice the rated power, and it simultaneously supports full-power charging and load operation.
It adopts three - stage charge - discharge conversion, which results in low current ripple and prolongs the service life of the battery.
It is equipped with a multi-functional generator interface, enabling intelligent switching and control, thus saving additional investment.
Both the AC input port and the generator interface can be connected to the PV grid-connected inverter for renovating the original PV system.
4.3-inch 65K-color HD touch screen, supporting customization of languages worldwide.
Set the charging and discharging time periods according to the time-of-use electricity price.
With an IP65 protection rating, it can be installed outdoors.
| MODEL | HC1030EH48L | HC1040EH48L | HC1050EH48L | HC1060EH48L |
|---|---|---|---|---|
| PV Input | ||||
| Max PV Input Power | 6000W | 4000W+4000W | 5000W+5000W | 6000W+6000W |
| Max PV Input Voltage | 500Vdc | |||
| PV Input Startup voltage | 90Vdc | |||
| MPPT Input Voltage | 120-425Vdc | |||
| MPPT Full Load Voltage Range | ||||
| PV Max Input Current | 18A | 18A+18A | ||
| PV Short-circuit Current | 26A | |||
| Number of MPPT / Strings per MPPT | 1/1 | 2/1+1 | ||
| AC Output | ||||
| Rated Output Voltage | 220V/230Vac | |||
| Output Frequency Range | 50/60Hz(±5), Intelligent adaptive/Settable | |||
| Rated Off-grid current | 13A | 17.4A | 21.8A | 26.1A |
| Max off-grid Power | 3000W | 4000W | 5000W | 6000W |
| Grid Type | Single Phase, L+N+PE | |||
| Output Power Factor | ＞0.99 @ Rated power (Adjustable 0.8 leading-0.8 lagging) | |||
| THDi | ＜3% | |||
| Transfer Time | ＜10ms | |||
| Off-grid Overload Capability | 101%-110% 30s, >110% 10s | |||
| Battery Input | ||||
| Battery Type | Lead-acid, lithium batteries, gel batteries, etc | |||
| Battery Voltage | 48Vdc(40V~60V) | |||
| Max Discharge Current | 75A | 100A | 110A | 120A |
| Max Charging Current | 60A | 100A | 110A | 120A |
| Max Discharge Power | 3000W | 4000W | 5000W | 6000W |
| Max Charging Power | 3000W | 4000W | 5000W | 6000W |
| AC Input | ||||
| Max. Input Power to Battery | 3000W | 4000W | 5000W | 6000W |
| Rated Input Voltage | 150-290Vac (140-310V Optional) | |||
| Rated Input Frequency | 50/60Hz(±5), Intelligent adaptive/Settable | |||
| Grid Input Current | 15A | 17.4A | 21.8A | 26.1A |
| Efficiency | ||||
| Max PV Conversion Efficiency | 97.6% | |||
| European Efficiency | 96.5% | |||
| MPPT Efficiency | ＞99% | |||
| General Parameters | ||||
| Display | Touch Screen+LED | |||
| Communication Mode | RS485/CAN，GPRS/WIFI/Bluetooth/4G/LAN (Optional) | |||
| Protection function | Grid/battery over- and undervoltage protection、Grid over- and underfrequency protection、Output short circuit/overload protection、PV reverse connection alarm、Battery charge and discharge overcurrent protection、Insulation impedance protection、Ground fault protection | |||
| Noise (dB) | ＜55 | |||
| Cooling | Intelligent fan (IP68) | |||
| Operating Ambient Temperature | -40°C~60°C(＞45℃ Derating ) | |||
| Humidity | 0~100% | |||
| Altitude | 3000m (>2000m Derating ) | |||
| Protection Degree | IP65 | |||
| Installation Method | Wall-mounted | |||
| Dimension. W*D*H(mm) | 320*170*440 | |||
| Gross Weight (kg) | 12 | 14 | 14.5 | 15 |
| Warranty | 5 years standard | |||
| Certifications | ||||
| Certifications standard | IEC/EN 61000-6-1/3 、IEC/EN 61000-3-11/12、EN 62920 、IEC 62109-1、IEC 62109-2、IEC 62321 | |||
Specifications are subject to change without advance notice.
Scenarios of no power, lack of power, power instability area, no motor and other impact load scene.
