LiFePO4 battery, safer and longer cycle life.
Abundant output ports to power multiple devices simultaneously.
It is equipped with the function of dimensionality-upgrading drive and has extremely strong load adaptability.
AC 96~144V ultra-wide charging voltage input range.
Accurate temperature control of battery, 5℃ lower than mainstream products, and longer battery life.
The hidden handle design makes it easier tocarry outdoors.
| Mains Electricity | 1.3 h |
| Charging Method | 3 Types |
| Safety Protection | 8 Layers |
| Output Port | 9 Pcs |
| Seamless Switching | ≤10 ms |
| 600U Charge-discharge Cycles | 4000 Times |
| 800U Charge-discharge Cycles | 3000 Times |
| MODEL | HPQ0600U | HPQ0800U |
|---|---|---|
| Battery Capacity | 512Wh | 768Wh |
| Output specifications | ||
| AC Output（*2） |
120Vac~5A,50/60Hz Total 600W(Peak 1200W) |
120Vac,6.7A,50/60Hz Total 800W(Peak 1600W) |
| AC Output bypass mode（*2） | 100~130Vac,50/60Hz, Max 9A | |
| USB-A 1 Fastcharge Output | 5/9/12Vdc,1.5A；Max 18W（*1） | 5/9/12Vdc,1.5A；Max 18W（*1） |
| USB-A2/3 Output | Single 5Vdc,2.4A; Tota l 5Vdc,3A;Max 15W（*2） | Single 5Vdc,2.4A;Max 12W（*1） |
| TYPE- C Output | 5/9/12/15Vdc,3A；20Vdc,5A;Max 100W（*1） | 5/9/12/15Vdc,3A；20Vdc,5A;Max 100W（*2） |
| DC12V Output (*2) | Single 12Vdc,3A,36W | |
| Car Charging Port Output | 12Vdc,10A, 120W Max | |
| LED Emergency Lighting | 2W,3 gear adjustment | |
| DC12V output and car charging port output power sharing, maximum output 120W. | ||
| Input specifications | ||
| Charging Power | 96~144Vac,50/60Hz,10A Max | |
| Charging Time | AC direct charging/1.3 hours | |
| Solar Charging Input | 11-55Vdc,Max 13A,300W | 11-55Vdc,Max 15A,400W |
| Car Charging Input | 12V/24Vdc,Max 8A,100W | |
| Battery parameters | ||
| Cell Material | LiFePO4 | |
| Battery Standard Cycle Life | 4000 cycles to 80+% capacity | 3000 cycles to 80+% capacity |
| Protection Features | High temperature protection, low temperature protection, charging overvoltage protection, discharge undervoltage protection, charging overcurrent protection, discharge overcurrent protection, overload protection, short circuit protection | |
| The standard cycle life of the battery is measured in the laboratory at an ambient temperature of 77℉, and the actual data will vary according to the specific use of the user. | ||
| General parameters | ||
| Dimension. W*D*H(mm) | 280*190*196mm（11*7.5*7.7inch) | 336*218*203（13.2*8.6*8inch） |
| Weight (kg) | 6.8kg（15Lbs） | 9.8kg（21.6Lbs） |
| Operating Environment | ||
| Charging Ambient Temperature | 0°C~45°C（32℉~113℉） | 0°C~40°C（32℉~104℉） |
| Discharge Ambient Temperature | -10°C~45°C（14℉~113℉） | -10°C~40°C（14℉~104℉） |
| Storage Ambient Temperature | -20°C~45°C（-4℉~113℉） | |
| Humidity | 10~95% (Non-condensing) | |
| Altitude | <2000m | |
| Protection Degree | IP20 | |
| Certifications | ||
| Authentication Certificate | CA65、TSCA、UN38.3、FCC、UL2743 | |
Note: Whether this series of products can be charged and discharged normally is determined by the actual temperature of the battery pack.
Specifications are subject to change without advance notice.
Digital entertainment, outdoor use, do whatever you want, no need to worry about power problems, say goodbye to battery life anxiety
