With smart BMS system.
High discharge current, strong load impact resistance.
Grade A Lithium Iron Phosphate Battery, Superior safety and reliability.
Wall-mounted installation design, space-saving, easy to install, and flexible for expansion.
Possess safety protection functions such as overcharge, over-discharge, overcurrent, high temperature, and low temperature.
RS485/CAN communication allows for real-time monitoring of battery status and setting of protection parameters.
| Parameter | BM051W48 |
| Battery | |
| Cell Material | Lithium Iron Battery (LiFePO4) |
| Battery Voltage | 51.2V |
| Battery Capacity | 5120Wh |
| Operation Voltage Range | 44.8~57.6V |
| Max Continuous Discharge Current | 100A |
| Standard Charging Current | 50A |
| Max Continuous Charge Current | 100A |
| Battery Standard Cycle Life | ≥6000 (25°C±2°C, 0.5C/0.5C, 80%DOD, 70%SOH) |
| Protection Features | |
| Protection Features | Overcharge protection, Overdischarge protection, Overcurrent protection, Short circuit protection, Overtemperature protection |
| General Parameters | |
| Display | LED indicator light / LED Display (Optional) |
| Dimension. W*D*H(mm) | 458*605*158 |
| Weight (NW Kg) | 44 |
| Chassis Installation Method | Wall-mounted |
| Terminal | M6 |
| Cooling | Natural convection |
| Protection Degree | IP20 |
| Communication | CAN/RS485 (Optional) |
| Operating Environment | |
| Storage Temperature | -30°C~60°C |
| Charging Temperature | -10°C~50°C |
| Discharge Temperature | -20°C~50°C |
| Humidity | 0%~95% Non-condensation |
| Operating Environment | Indoor |
| Certifications | |
| Certifications | UN38.3, RoHS, CE, MSDS |
